LQ Relays | Power Relays ( Over 2A )

Download

  • Lineup

  • Basic Information

Compliant with IEC/EN60335-1*1*2, IEC/EN60079-15*3 1 Form A/1 Form C 10 A small power relays

UL/C-UL,VDE,CQC,UL/C-UL (Hazardous Location) ANSI Approved

Compliant with IEC/EN60335-1 *1*2(VDE approved)
Compliant with IEC/EN60079-15 *3
CSA standard certified by C-UL
*1: Common safety standard for major electrical appliance
*2: 1 Form A type is compatible except for the bottom surface
*3: Explosion-proof certification

    • Protective construction: Sealed

    Please refer to "the latest product specifications" when designing your product.
    Please refer to "Cautions For Use" in the catalog, and "Related Information" on our website.

      • Features

        • Compact with high capacity: 1 Form A / 1 Form C, 10 A
        • Inrush/reinforced insulation type has TV-3 rating ( UL/C-UL approved )
        • Compliant with IEC/EN60335-1*1 *2 (VDE approved)
          *1: Common safety standard for major electrical appliance
          *2: 1 Form A type is compatible except for the bottom surface
        • Compliant with IEC/EN60079-15*3 (VDE approved)
          *3: Explosion-proof certification

      • Typical Applications

        1. Home appliance
        2. Industrial equipment
      • Lineup
      • Discontinued Products
      LQ Relays Product number list
      No matching products found.
      • Please review your search criteria and try again.
      • If you have any questions, feel free to contact us.

        • Notes）

          1. The "S" at the end of the part number only appears on the inner and outer packing.
            It does not appear on the relay itself.
          2. 48 V DC types is also available. Please contact our sales representative for details.
          3. Inrush/reinforced insulation type are Class F insulation, 12 V DC, 24 V DC only.
          4. Reflow soldering type is only tube.
